- Size: 20
- Place of Origin: Shandong China
- Brand Name: shengya
- Model Number: QT4-15
- Weight: 5000.000 kg
- :
- :
- :
- :
- :
- :
1).Mould structure: we design the mould structure specially in order to change the mould easily,about the
mould lifespan ,we use the newst heat treatment equipment to do carburization work
2).About the electricity motor ,in Mixer and host machine ,we will use Germany siemens motor ,because this
two part nearly working all time in working day ,so we could use high level hard wearing motor for this ,and ther
motor we will also use CE standard ,
3).About the switches ,we will select the France Schneider brand , it is could assure the working process smoothly .
4).The Control System Using computer control and man machine interface. Electrical equipments apply
the well-known brands from Japan and Germany, like Japan Mitsubishi .
- Size: 20
- Place of Origin: Shandong China
- Brand Name: shengya
- Model Number: QT4-15
- Weight: 5000.000 kg
- :
- :
- :
- :
- :
- :
Dimension of host machine | 3800×1800×2550mm | |||
Moulding area | 400×800mm | |||
Moulding period | 15-25S | |||
The size of the pallet | 850×550×25/30mm | |||
Weight of the host machine | 4.6T | |||
Host machine power | 19.2 KW | |||
Vibration force | 40KN | |||
Mixer model | JS500 | |||
General water Consumption | 4T/every day | |||
Voltage | 380V,according to client local voltage |
Size(LxWxH) | Pcs/Mould | Pcs/ Hr | Pcs/ 8 Hr | ||||
230×110×70 | 24 | 4320 | 34560 | ||||
400X100X200 | 8 | 1200-1920 | 9600-15360 | ||||
400X150X200 | 6 | 900-1440 | 7200-11520 | ||||
400X200X200 | 4 | 600-960 | 4800-7680 | ||||
400x250x250 | 3 | 450-720 | 3600-5760 |
